Features:
* High reliability and durability design
* Multiple product selections
* High accuracy, OIML/MID certified
* Classic L-Frame design
* 2/4/6/8/10/12 hoses
* Standard and High flow rate
* Multiple connectivity(CL,RS485, RJ45, LON)
* Multiple options and customized features
Featured parts :
.png)
Optional Configuration:
Printer, IC card, ID card, Hose retractor, communication for FMS, vapor recovery, break away,swivel, emergency stop, LED light,ect
Technical specifications:
|
Accuracy for the unit |
±0.25% |
|
Flow rate |
5-50L/min, 8-80L/min,12-120L/min |
|
Ambient temperature |
-25℃~ +55℃; -45℃~ +55℃ |
|
Relative humidity |
20% ~ 95% |
|
Unit noise rate |
< 70dB (A) |
|
Inlet vacuum rate for suction pump |
≧54kPa |
|
Communication |
CL,RS485, RJ45, LON |
|
Power supply |
AC 110V( -15%~+10%),(50/60±1)Hz AC 220V( -15%~+10%),(50/60±1)Hz ; AC 380V( -15%~+10%),(50/60±1)Hz |
|
Digit of sale |
7digits (decimal points can be adjusted ) |
|
Digit of volume |
6digits (decimal points can be adjusted ) |
|
Digit of unit price |
5digits (decimal points can be adjusted ) |
|
Totalizer of sale |
0~42949672.95 |
|
Totalizer of volume |
0~42949672.95 |
Dimensions:
Optional model:
Model
Nozzle
Product
Display(1/side)
Package Size(mm)
G.W.(kg)
SK65G/Q/ZF212B
2
1
2
1100X780X2150
370/330/360
SK65G/Q/ZF422B
4
2
2
1300x780x2150
440/360/420
SK65G/Q/ZF632B
6
3
2
1640x780x2150
540/420/510
SK65G/Q/ZF842B
8
4
2
2080x780x2150
690/530/650
G: Gear pump Q: submersible pump Z: Vane pump
